6-1-1 Tesla C-Mag 3-Axis Optical Superconducting Magnet System

C-Mag Vari-611-Optical, 6-1-1 Tesla 3-Axis Optical Cryogen-FREE superconducting magnet system cooled by a single Pulse Tube cryocooler to conductively cool the magnet and cryostat as well as cooling a secondary closed loop helium circuit used for controlling the sample temperature. Optical access in all horizontal magnetic axes with ports threaded to accept interchangeable Thorlabs lens assemblies.

Customer Location: New Jersey, USA

• 6-1-1 Tesla 3-Axis Superconducting Magnet with up to 6 Tesla in non-vector operation and up to 1 Tesla in spherical vector mode.

• +/- 0.5% Z-Axis Homogeneity over 1cm DSV

• +/- 1.0% X and Y-axis Homogeneity Over 1cm DSV

• 49mm ID, <1.8K-300K Sample space.

• 5 Optical access ports (4-X/Y, 1-Z) each port threaded to accept Thorlabs optics.

• 22o total viewing angle horizontal optical pathways.

• Bottom mounted optical window for 25mm parallel viewing path.

• Single, Cryomech 1.5W Pulse-Tube Cryocooler, Remotely mounted motor.

Delivered: May, 2022
